| Camera Module |
| Image Sensor |
1/2.8" progressive scan CMOS |
| Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON);
B/W: 0.001 Lux @(F1.6, AGC ON) |
| White Balance |
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC |
Auto/Manual |
| Day & Night |
IR Cut Filter |
| Shutter Time |
1/1 s to 1/30,000 s |
| Digital Zoom |
16X |
| Privacy Mask |
24 programmable privacy masks |
| Focus Mode |
Auto/Semi-automatic/Manual |
| WDR |
120 dB WDR |
| Lens |
| Focal Length |
5 mm to 75 mm, 15× optical |
| Zoom Speed |
Approx. 2.4 s (optical lens, wide-tele) |
| Field of View |
Horizontal field of view: 53.8° to 4.0° (wide-tele);
Vertical field of view: 31.9° to 2.3° (wide-tele);
Diagonal field of view: 60.4° to 4.6°(wide-tele) |
| Working Distance |
10 mm to 1500 mm (wide-tele) |
| Aperture Range |
F1.6 to F3.0 |
| IR |
| IR Distance |
Up to 100m |
| Smart IR |
Support |
| PTZ |
| Pan and Tilt Range |
Pan:360° endless; Tilt: -15°~90°(Auto Flip) |
| Pan and Tilt Speed |
Configurable, from 0.1°/s to 80°/s
Preset Speed: 80°/s |
| Proportional Zoom |
Support |
| Number of Preset |
300 |
| Patrol |
8 patrols, up to 32 presets for each patrol |
| Pattern |
4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory |
Support |
| Park Action |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| PTZ Position Display |
Support |
| Preset Freezing |
Support |
| Scheduled Task |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust |
| Compression Standard |
| Video Compression |
H.265+/H.265/H.264+/H.264 |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.264+ |
Support |
| H.265 Type |
Main Profile |
| H.265+ |
Support |
| Video Bitrate |
32 Kbps to 16384 Kbps |
| SVC |
Support |
| Smart Feature |
| Basic Event Detection |
Motion Detection, Video Tampering Detection, Exception Detection |
| Smart Event Detection |
Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection |
| ROI encoding |
Main stream, sub-stream and third stream respectively support four fixed areas. |
| Smart Record |
ANR (Automatic Network Replenishment), Dual-VCA |
| Image |
| Max. Image Resolution |
1920 x 1080 |
| Stream |
Support three Streams |
| Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Image Enhancement |
HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus |
| Network |
| Network Storage |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| API |
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform |
| Simultaneous Live View |
Up to 20 channels |
| User/Host |
Up to 32 users.
3 levels: Administrator, Operator and User |
| Security Measures |
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
| Mini SD Memory Card |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Interface |
| Network Interface |
1 RJ45 10 M/100 M Ethernet Interface; PoE+ (802.3at, class4) |
| General |
| Power |
12 VDC and PoE+ (802.3at, class4)
Max.: 18 W (IR light 6 W Max.) |
| Working Temperature |
-30°C to 65°C (-22°F to 149°F) |
| Working Humidity |
≤ 90% |
| Protection Level |
IP66 Standard; TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Material |
ADC 12, PC+10% GF |
| Dimensions |
Φ 165.9 mm × 290 mm (Φ 6.53" × 11.42") |
| Weight (approx.) |
Approx. 2.5 kg (5.51 lb) |
