| Camera Module |
| Image Sensor |
1/3" progressive scan CMOS |
| Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON) |
| White Balance |
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC |
Auto/Manual |
| Day & Night |
IR Cut Filter |
| Shutter Time |
50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s |
| Digital Zoom |
16× |
| Privacy Mask |
24 programmable privacy masks |
| Focus Mode |
Auto/Semi-automatic/Manual |
| WDR |
120 dB WDR |
| Lens |
| Focal Length |
2.8 mm to 12 mm, 4× optical zoom |
| Zoom Speed |
Approx. 2 s (optical lens, wide-tele) |
| Field of View |
Horizontal field of view: 100° to 33° (Wide-Tele)
Vertical field of view: 53° to 18° (Wide-Tele)
Diagonal field of view: 119° to 37.5° (Wide-Tele) |
| Working Distance |
10 mm to 1500 mm (wide-tele) |
| Aperture Range |
F1.6 to F2.7 |
| IR |
| IR Distance |
20 m |
| Smart IR |
Support |
| PTZ |
| Pan and Tilt Range |
Pan:0° to 330°, Tilt: 0° to 90° |
| Pan and Tilt Speed |
Configurable, from 0.1°/s to 100°/s, Preset speed: 100°/s |
| Proportional Zoom |
Support |
| Number of Preset |
300 |
| Power-off Memory |
Support |
| Compression Standard |
| Video Compression |
H.265+/H.265/H.264+/H.264 |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.264+ |
Support |
| H.265 Type |
Main Profile |
| H.265+ |
Support |
| Video Bitrate |
32 Kbps to 16384 Kbps |
| Audio Compression |
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Audio Bitrate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2) |
| SVC |
Support |
| Smart Feature |
| Basic Event Detection |
Motion Detection, Video Tampering Detection, Exception |
| Smart Event Detection |
Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection |
| ROI encoding |
Main stream, sub-stream, and third stream respectively support two fixed areas. |
| Smart Record |
ANR (Automatic Network Replenishment), Dual-VCA |
| Image |
| Max. Image Resolution |
2560 × 1440 |
| Stream |
Support three steams |
| Main Stream |
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 24fps (2560 × 1440), 30fps (2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream |
50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Image Enhancement |
3D DNR, HLC, EIS, Regional Exposure, Regional Focus |
| Network |
| Network Storage |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| API |
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform, support Hik-Connect |
| Simultaneous Live View |
Up to 20 channels |
| User/Host |
Up to 32 users
3 levels: Administrator, Operator and User |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
| Mini SD Memory Card |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Interface |
| Audio Input |
1-ch |
| Audio Output |
1-ch |
| Network Interface |
1 RJ45 10 M/100 M Ethernet, PoE |
| General |
| Power |
12 VDC & PoE
Max.: 12 W (Max. 3.9 W for IR) |
| Working Temperature |
-20°C to 60°C (-4°F to 140°F) |
| Working Humidity |
≤ 90% |
| Protection Level |
IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Material |
Aluminum alloy, PC, PC+ABS |
| Dimensions |
Φ 130.7 mm × 101.7 mm (Φ 5.15" × 4.00") |
| Weight (approx.) |
Approx. 0.53 kg (1.17 lb) |
