| Camera |
| Appearance |
Dome |
| Image Sensor |
1/3" progressive scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @(F1.2, AGC ON), 0.018Lux @ (F1.6, AGC ON) |
| Shutter Speed |
1/3 s to 1/100, 000 s, support slow shutter |
| Slow Shutter |
Yes |
| Auto-Iris |
No |
| Day & Night |
IR cut filter |
| Digital Noise Reduction |
3D DNR |
| WDR |
120 dB |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 70°, rotation: 0° to 360° |
| Lens |
| Focal Length |
2.8 to 12 mm |
| Aperture |
F1.6 |
| Focus |
Auto |
| Angle of view |
Horizontal field of view: 98° to 28°, Vertical field of view: 51° to 16°, Diagonal field of view: 115° to 32° |
| Lens Mount |
Φ14 |
| IR |
| IR Range |
Up to 30 m |
| Wavelength |
850 nm |
| Compression Standard |
| Video Compression |
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.264+ |
Main stream supports |
| H.265 Type |
Main Profile |
| H.265+ |
Main stream supports |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Smart Feature-Set |
| Region of Interest |
1 fixed region for main stream and sub-stream |
| Image |
| Resolution |
4MP |
| Main Stream Max. Frame Rate |
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| Sub-stream Max. Frame Rate |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Image Enhancement |
BLC, 3D DNR |
| Image Setting |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day/Night Switch |
Auto, scheduled |
| Network |
| Alarm Trigger |
Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login |
| Network Storage |
Support micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| General Function |
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI |
| Simultaneous Live View |
Up to 6 channels |
| User/Host |
Up to 32 users
|
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
IE8+, Chrome 31.0-44, Firefox 30.0-51 |
| Interface |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| On-board storage |
Built-in micro SD/SDHC/SDXC card slot, up to 128 GB |
| Reset Button |
Yes |
| General |
| Operating Conditions |
-30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3) |
| Power Consumption |
12 VDC, 0.8 A, max: 10 W;
PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max: 12 W |
| Ingress Protection level |
IP67 |
| Impact Protection |
IK10 |
| Material |
Metal & Plastic |
| Dimensions |
Camera: Ø 141.2 mm × 99.6 mm (Ø 5.6" × 3.9")
With package: 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1") |
| Weight |
Camera: approx. 820 g (1.8 lb.)
With package: approx. 1200 g (2.6 lb.) |
