| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON) |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Auto-Iris |
No |
| Day &Night |
IR Cut Filter |
| DNR |
3D DNR |
| Wide Dynamic Range |
DWDR |
| 3-Axis Adjustment |
Pan: 0° to 360°, tilt: -90° to 90°, rotate: 0° to 90° |
| Lens |
| Focal length |
2.8 mm |
| Aperture |
F2.0 |
| Focus |
Fixed |
| Lens Mount |
M12 |
| IR |
| IR Range |
Up to 30 m |
| Compression Standard |
| Video Compression |
Main stream: H.264
Sub-stream: H.264, MJPEG |
| H.264 Type |
Baseline Profile/Main Profile |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32 to 160Kbps(MP2L2) |
| Image |
| Max. Resolution |
1920 × 1080 |
| Main Stream Max. Frame Rate |
50Hz: 25fps (1920 × 1080, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 720) |
| Sub Stream Max. Frame Rate |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day/Night Switch |
Day, night, auto, scheduled |
| Network |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour |
| General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
| Interface |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Audio Interface |
1 Built-in mic, mono sound |
| Wi-Fi |
| Wireless Standards |
IEEE 802.11b/g/n |
| Frequency Range |
2.4 GHz to 2.4835 GHz |
| Channel Bandwidth |
20 MHz/40 MHz |
| Protocols |
802.11b: CCK, DQPSK, DBPSK
802.11g/n: 64-QAM, 16-QAM, QPSK, BPSK |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transfer Rates |
11b: 11 Mbps, 11g: 54 Mbps, 11n: up to 150 Mbps |
| Wireless Range |
Up to 50 m (The performance varies based on actual environment) |
| General |
| Operating Conditions |
-30 °C to +60 °C (-22°F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, 5.5 mm coaxial power plug |
| Current |
0.4 A |
| Power Consumption |
max. 5 W |
| Material |
Front cover: metal, back cover: plastic |
| Dimensions |
Camera: 99 mm × 68 mm × 66 mm (3.9" × 2.7" × 2.6")
With package: 172 mm × 110 mm × 99 mm (6.8" × 4.3" × 3.9") |
| Weight |
Camera: 272 g (0.6 lb.)
With package: 517 g (1.1 lb.) |
